Sharp XL-DH330PH

XL-DH330PH_09 EN.fm
E-5
20/07/10
Remote control
Caution:
● Replace all old batteries with new ones at the same time.
● Do not mix old and new batteries.
● Remove the batteries if the unit will not be used for a long period
of time. This will prevent potential damage due to battery
leakage.
● Do not use rechargeable batteries (nickel-cadmium battery, etc.).
● Installing the batteries incorrectly may cause the unit to
malfunction.
● Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
Notes concerning use:
● Replace the batteries if the operating distance is reduced or if the
operation becomes erratic. Purchase 2 “AAA” size batteries (UM/
SUM-4, R3, HP-16 or similar).
● Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
● Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit if this
occurs.
● Keep the remote control away from moisture, heat, shock, and
vibrations.
Check the remote control after checking all the connections.
Point the remote control directly at the remote sensor on the unit. The
remote control can be used within the range shown below:
General control
Press the ON/STAND-BY button to turn the power on.
To dim the display brightness, prees the DEMO/DIMMER button on
the remote control.
If you turn off and on the main unit with the volume set to 27 or higher,
the volume starts at 16 and fades in to the last set level.
Turn the volume knob towards VOL +/– (on main unit) or press
VOLUME +/– (on remote control) to increase or decrease the volume.
When you press any of the following buttons, the unit turns on.
● iPod/iPhone, CD, USB, AUDIO IN, TUNER (BAND) on the
remote control: Selected function is activated.
● / button on the main unit: The unit turns on and playback of
the last function will start (CD, TUNER, USB, iPod, AUDIO IN).
The main unit will enter the stand-by mode (when iPod/iPhone is not
docked) after 15 minutes of inactivity during:
iPod/iPhone: No connection.
AUDIO IN: No detection of input signal or very low sound audibility.
TUNER: No reception of broadcast signal.
CD/USB: In the stop mode.
Note:
However, if iPod/iPhone is docked, the unit will begin charging.
“CHARGE MODE” will be displayed.
The volume is muted temporarily when pressing the MUTE button on
the remote control. Press again to restore the volume.
When the power is first turned on, the unit will enter the extra bass
mode which emphasises the bass frequencies, and “X-BASS” will
appear. To cancel the extra bass mode, press the X-BASS button on
the remote control.
1 Press the BASS/TREBLE button to select “BASS”.
2 Within 5 seconds, press the VOLUME (+ or –) button to adjust the
bass.
■ Battery installation
1
Open the battery cover.
2
Insert the supplied batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the
(–) battery terminals.
3
Close the cover.
■ Test of the remote control
0.2 m - 6 m
(8" - 20' )
Remote sensor
■ To turn the power on
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
■ Display brightness control
■ Volume auto fade-in
■ Volume control
■ Auto power on function
■ Auto power off function
■ Muting
■ X-Bass control
■ Bass control
