Sharp XL-DV60 Service Manual

XL-DV60
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INTEGRATED CIRCUITS
IC101 VHILM4781TA-1 AZ N Power Amp.,LM4781TA
IC201 VHIKIA7805API AF Voltage Regulator,KIA7805API
IC202 VHIKIA7812API AE Voltage Regulator,KIA7812API
IC203 VHILM2576T/-1 AR Voltage Regulator,LM2576T
IC204 VHIAN78L05/-1 AE Constant Voltage Regulator,AN78L05
IC301 VHITA7358AP-1 AG FM Front End,TA7358AP
IC302 VHILC72131/-1 AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 AN FM IF Det./FM Mpx./AM IF,LA1832S
IC601 VHILC75341M-1 AM Signal Control,LC75341M
IC602 VHINJM4558D-1 AH Buffer Amp.,NJM4558D or AN4558
IC603 VHILC75341M-1 AM Signal Control,LC75341M
IC701 RH-IXA009SJZZ AV System Microcomputer,IXA009SJ
IC702 VHIAT24C04/-1 AH EEPROM,AT24C04
[2] TRANSISTORS
Q101 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q102 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q107 VS2SC3052F+-1 AD Silicon,NPN,2SC3052F+
Q108 VS2SC3052F+-1 AD Silicon,NPN,2SC3052F+
Q109 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q110 VSKRA107M//-1 AE Digital,PNP,KRA107 M
Q111 VSKRC107M//-1 AC Digital,NPN,KRC107 M
Q112 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q113 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q114 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q115 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q116 VSKRC107M//-1 AC Digital,NPN,KRC107 M
Q117 VS2SB562-C/-1 AD Silicon,PNP,2SB562 C
Q118 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q201 VS2HA1015GR-1 AB Silicon,PNP,2HA1015 GR
Q202 VS2SC535-C/-1 AC Silicon,NPN,2SC535 C
Q203 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR
Q204 VS2HA1015GR-1 AB Silicon,PNP,2HA1015 GR
Q205 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q206 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q207 VS2SC3052F+-1 AD Silicon,NPN,2SC3052F+
Q208 VS2SA1235F+-1 AD Silicon,PNP,2SA1235F+
Q213 VS2SB562-C/-1 AD Silicon,PNP,2SB562 C
Q214 VS2SC3052F+-1 AD Silicon,NPN,2SC3052F+
Q302 VS2SC535-C/-1 AC Silicon,NPN,2SC535 C
Q306 VS2SC535-C/-1 AC Silicon,NPN,2SC535 C
Q351 VSKRC104M//-1 AC Digital,NPN,KRC104 M
Q360 VS2HA1015GR-1 AB Silicon,PNP,2HA1015 GR
Q502 VSKRC102M//-1 AC Digital,NPN,KRC102 M
Q503 VS2SB562-C/-1 AD Silicon,PNP,2SB562 C
Q504 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q505 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y
Q506 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q507 VS2HC1815GR-1 AB
Silicon,NPN,2HC1815 GR
Q508 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y
Q509 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q511 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q702 VSKRC102M//-1 AC Digital,NPN,KRC102 M
Q703 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q704 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q705 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
[3] DIODES
D104 VHD1N4148//-1 AA Silicon,1N4148
D105 VHD1N4148//-1 AA Silicon,1N4148
D106 VHD1N4148//-1 AA Silicon,1N4148
D107 VHD1N4004//-1 AB Silicon,1N4004
D108 VHD1N4148//-1 AA Silicon,1N4148
D109 VHD1N4004//-1 AB Silicon,1N4004
D110 VHD1N4004//-1 AB Silicon,1N4004
D111 VHD1N4004//-1 AB Silicon,1N4004
D112 VHD1N4004//-1 AB Silicon,1N4004
D201 VHDTS6B04GM-1 AP Silicon,TS6B04GM-1
D202 VHD1N4148//-1 AA Silicon,1N4148
D205 VHDKBP304GM-1 AF Silicon,KBP304GM-1
D209 VHD1N4004//-1 AB Silicon,1N4004
D210 VHD1N4004//-1 AB Silicon,1N4004
D211 VHD1N4004//-1 AB Silicon,1N4004
D212 VHD1N4004//-1 AB Silicon,1N4004
D213 VHD1N4004//-1 AB Silicon,1N4004
!
D214 VHD1N4004//-1 AB Silicon,1N4004
!
D215 VHD1N4004//-1 AB Silicon,1N4004
!
D216 VHD1N4004//-1 AB Silicon,1N4004
!
D217 VHD1N4004//-1 AB Silicon,1N4004
D218 VHD1N4004//-1 AB Silicon,1N4004
D219 VHD1N4004//-1 AB Silicon,1N4004
D231 VHD1N5822//-1 AD Silicon,1N5822
D232 VHD1N4004//-1 AB Silicon,1N4004
D301 VHD1N4148//-1 AA Silicon,1N4148
D302 VHD1N4148//-1 AA Silicon,1N4148
