XL-DV60
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
D305 VHD1N4148//-1 AA Silicon,1N4148
D306 VHD1N4148//-1 AA Silicon,1N4148
D307 VHD1N4148//-1 AA Silicon,1N4148
D308 VHD1N4148//-1 AA Silicon,1N4148
D604 VHD1N4148//-1 AA Silicon,1N4148
D605 VHD1N4148//-1 AA Silicon,1N4148
D701 VHD1N4004//-1 AB Silicon,1N4004
D702 VHD1N4148//-1 AA Silicon,1N4148
D703 VHD1N4148//-1 AA Silicon,1N4148
D704 VHD1N4148//-1 AA Silicon,1N4148
D705 VHD1N4148//-1 AA Silicon,1N4148
D706 VHD1N4004//-1 AB Silicon,1N4004
D708 VHD1N4004//-1 AB Silicon,1N4004
D709 VHD1N4148//-1 AA Silicon,1N4148
D710 VHD1N4148//-1 AA Silicon,1N4148
D712 VHD1N4148//-1 AA Silicon,1N4148
D713 VHD1N4148//-1 AA Silicon,1N4148
LED701 VHPLP3052A+-1 AC LED,Red,LP3052A+
VD301 VHCSVC348S/-1 AK Variable Capacitance,SVC348S
VD302 VHCKDV147B/-1 AH Variable Capacitance,KDV147B
VD303 VHCKDV147B/-1 AH Variable Capacitance,KDV147B
ZD101 VHEDZH06B2+-1 AB Zener,6.2V,DZH06B2+
ZD201 VHEDZH3001+-1 AB Zener,30V,DZH3001+
ZD202 VHEDZH06C2+-1 AB Zener,6.2V,DZH06C2+
ZD351 VHEDZH05C2+-1 AB Zener,5.1V,DZH05C2+
ZD701 VHEDZH03C3+-1 AB Zener,3.3V,DZH03C3+
[4] FILTERS
BF301 RFILRA001SJZZ AD Band Pass Filter
CF302 RFILF0004SJZZ AG FM IF,10.7 MHz
CF303 RFILF0004SJZZ AG FM IF,10.7 MHz
CF351 RFILF0003AWZZ AK FM IF
CF352 RFILA0003SJZZ AF AM IF
[5] TRANSFORMERS
!
T201 RTRNPA036SJZZ N Power (Main)
!
T202 RTRNP0056SJZZ AM Power (Sub)
T302 RCILAA002SJZZ AC AM Antenna
T304 RCILI0005SJZZ AF FM IF
T306 RCILBA006SJZZ AC AM OSC.
T351 RCILI0004SJZZ AF AM IF
[6] COILS
L103 VP-DH100K0000 AB 10 µ H,Choke
L105 VP-DH2R2K0000 AB 2.2 µ H,Peaking
L206 RCILCA001SJZZ AD 100 µ H
L302 RCILR0003SJZZ AD FM RF
L303 RCILB0016SJZZ AD FM OSC.
L351 VP-DH101K0000 AB 100 µ H,Choke
L352 VP-DH101K0000 AB 100 µ H,Choke
L353 VP-DH102K0000 AB 1 mH,Choke
L502 VP-DHR82K0000 AE 0.82 µ H,Choke
L503 VP-DHR82K0000 AE 0.82 µ H,Choke
L601 VP-DH2R2K0000 AB 2.2 µ H,Peaking
L701 VP-DHR82K0000 AE 0.82 µ H,Choke
L702 RCILCA003SJZZ AB 2.4 µ H,Choke
L703 VP-DHR82K0000 AE 0.82 µ H,Choke
L704 VP-DHR82K0000 AE 0.82 µ H,Choke
L705 VP-DHR82K0000 AE 0.82 µ H,Choke
L707 VP-DHR82K0000 AE 0.82 µ H,Choke
L708 VP-DHR82K0000 AE 0.82 µ H,Choke
L901 RCILCA002SJZZ AB 10 µ H
L902 RBLN-A001SJZZ AB Ferrite Bead,120 ohms
L903 RBLN-A001SJZZ AB Ferrite Bead,120 ohms
L904 RBLN-A001SJZZ AB Ferrite Bead,120 ohms
L905 RBLN-A001SJZZ AB Ferrite Bead,120 ohms
L906 RBLN-A001SJZZ AB Ferrite Bead,120 ohms
L907 RBLN-A001SJZZ AB Ferrite Bead,120 ohms
!
LF201 RCILZ0005SJZZ AF Line Filter
[7] VARIABLE RESISTORS
VR351 RVR-M0026AWZZ AC 10 kohm (B),Semi-VR [FM Mute Level]
[8] VIBRATORS
X351 RCRM-0007SJZZ AG VCO,456 kHz
X352 RCRSP0003SJZZ AL Crystal,4.5 MHz
X701 RCRSPA007SJZZ AE Crystal,32.768 kHz
X702 RCRM-0008SJZZ AG Ceramic,8 MHz
[3] DIODES
