XL-MP130
8 – 7
IC701 RH-iXA056AWZZ: System Microcomputer (IXA056AW) (1/2)
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Pin No. Port Name Terminal Name Input/Output Function
1 AVDD AVDD - ANALOG POWER SUPPLY 5V
2 ANI0 KEY0 Input KEY0 INPUT
3 ANI1 KEY1 Input KEY1 INPUT
4 ANI2 KEY2 Input KEY2 INPUT
5 ANI3 VOL_JOG Input VOLUME JOG INPUT
6 ANI4 PROTECT Input POWER ABNORMAL DETECT
7 ANI5 T_FP SW Input TAPE FOOL PROOF A&B SW
8 ANI6 NO USE Input CONNECT TO GND
9 ANI7 T_RUN PULS Input TAPE RUN PULSE DETECT
10 ANI8 DISC&CLAMP Input 5-CHANGER DISC SW&CLAMP SW
11 ANI9 TRAY SW1&2 Input 5-CHANGER TRAY SW1&2
12 ANI10 CD-INTB Input CD SERVO INTERRUPTION SIGNAL
13 ANI11 MP3-INTB Input MP3 SERVO INTERRUPTION SIGNAL
14 AVSS AVSS — ANALOG GROUND
15 VSS1 VSS — GROUND VOLTAGE
16 X1 XIN Input CLOCK INPUT
17 X2 XOUT Output CLOCK OUTPUT
18 VDD1 VDD — POWER SUPPLY 5V
19 VPP VPP — CONNECT TO GND
20 P20 CD_CE Output CD CHIP ENABLE
21 SI0 CD_DO Input CD DATA INPUT
22 SO0 CD_DI Output CD DATA OUTPUT
23 SCK0 CD_CLK Output CD CLOCK
24 INTP2 P-IN Input POWER FAILURE DETECT
25 P66 PHOTO Input 5-CHANGER PHOTO SW
26 INTP1 SP_DET Input SPEAKER ABNORMAL DETECT
27 INTP0 REMOCON Input REMOCON INPUT
28 P63 CE Output CE OUTPUT
29 P62 CLK Output CLOCK OUTPUT
30 P61 DI Output DATA OUTPUT
31 P60 DO Input DATA INPUT
32 P57 CD_RESOUT Output CD RESET
33 P56 MOT_A+ Output 5-CHANGER CAM MOTOR(+)
34 P55 MOT_A- Output 5-CHANGER CAM MOTOR(-)
35 P54 TIMER LED Output TIMER LED
36 P53 S MUTE Output SYSTEM MUTE CONTROL
37 P52 T_SOL Output TAPE SOLENOID CONTROL
38 P51 T_MOTOR Output TAPE MOTOR CONTROL
39* P50 NO USE Output OPEN
40 VSS0 VSS — GROUND VOLTAGE
41 VDD0 VDD — POWER SUPPLY 5V
42 RESET RESET Input RESET INPUT
43 P47 ILLU_LED Output ILLUMINATION LED
44* P46 NS_SW2 Output NEW SOUND MODE SW2
45* P45 NS_SW1 Output NEW SOUND MODE SW1
46* P44 RDS_RST Output RDS RESET
47* P43 RDS_READY Input RDS READY
48* P42 RDS_RDDA Input RDS DATA
49* P41 RDS_RDCL Output RDS CLOCK
50 P40 DIST Input DESTINATION INPUT
51 P107 T_BIAS Output TAPE RECORD BIAS CONTROL
52 P106 T_REC/PLAY Output TAPE REC/PLAY CONTROL
53* P105 SP_LED Output SPEAKER LED
