XL-MP130
8 – 8
IC701 RH-iXA056AWZZ: System Microcomputer (IXA056AW) (2/2)
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Pin No. Port Name Terminal Name Input/Output Function
54 P104 -20dBATT Output -20dB ATTENUATOR
55 P103 SP_RLY Output SPEAKER RELAY CONTROL
56 P102 AC_RLY Output AC RELAY CONTROL
57-67 FIP41-FIP31 S30-S20 Output FL SEGMENT DRIVER
68 FIP30 S19/DEST1 Output FL SEGMENT DRIVER/DESTINATION OUTPUT
69 FIP29 S18/DEST2 Output FL SEGMENT DRIVER/DESTINATION OUTPUT
70 FIP28 S17/DEST3 Output FL SEGMENT DRIVER/DESTINATION OUTPUT
71 FIP27 S16/DEST4 Output FL SEGMENT DRIVER/DESTINATION OUTPUT
72-78 FIP26-FIP20 S15-S9 Output FL SEGMENT DRIVER
79 VDD2 VDD POWER SUPPRY 5V
80 VLOAD VLOAD VLOAD-35V
81-88 FIP19-FIP12 S8-S1 Output FL SEGMENT DRIVER
89-100 FIP11-FIP0 G12-G1 Output FL GRID DRIVER
