XL-MP130

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PART

RANK

DESCRIPTION

[1] INTEGRATED CIRCUITS

IC1 VHILC78690E-1 BE MP3 Decoder/Digital Signal Processor,LC78690E

IC2 VHILA6261//-1 AN Focus/Tracking/Spin/Sled Driver,LA6261

IC101 VHIAN7345K/-1 AM Playback and Record/Playback Amp.,AN7345K

IC301 VHITA7358AP-1 AG FM Front End,TA7358AP

IC302 VHILC72131/-1 AP PLL (Tuner),LC72131

IC303 VHILA1832S/-1 AN FM IF Det./FM Mpx./AM IF,LA1832S

IC601 VHILC75341/-1 AM Audio Processor,LC75341

IC701 RH-IXA056AWZZ System Microcomputer,IXA056AW

IC851 VHIKIA7812AP1 AF Constant Voltage Regulator,KIA7812AP

IC852 VHIKIA7810AP1 AF Constant Voltage Regulator,KIA7810AP

IC853 VHIKIA7805AP1 AF Constant Voltage Regulator,KIA7805AP

IC854 VHIKIA78L05-1 AF Constant Voltage Regulator,KIA78L05

IC901 VHISTK41249-1 AZ Power Amp.,STK412-490

[2] TRANSISTORS

IC855 VSKTC2026//-1 AF Silicon,NPN,KTC2026

Q1 VSKTA1504Y/-1 AB Silicon,PNP,KTA1504 Y

Q2 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y

Q3 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q4 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q101 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q102 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q103 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q104 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q105 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q106 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q107 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q108 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q109 VSKTA1504GR-1 AB Silicon,PNP,KTA1504 GR

Q110 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q111 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y

Q112 VSKTA1504GR-1 AB Silicon,PNP,KTA1504 GR

Q113 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q114 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q302 VSKTC3194Y/-1 AD Silicon,NPN,KTC3194 Y

Q360 VSKTA1504GR-1 AB Silicon,PNP,KTA1504 GR

Q601 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q602 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q607 VSKRA102S//-1 AB Digital,PNP,KRA102 S

Q701 VSKTA1273Y/-1 AE Silicon,PNP,KTA1273 Y

Q702 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y

Q703 VSKRC102S//-1 AB Digital,NPN,KRC102 S

Q712 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q713 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q714 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q715 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q719 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q801 VSKTA1274Y/-1 AE Silicon,PNP,KTA1274 Y

Q841 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR

Q850 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q901 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q902 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q903 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q904 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q905 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q906 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y

[3] DIODES

D1 VHDKDS184//-1 AB Silicon,KDS184

D301 VHD1N4148H/-1 AA Silicon,1N4148H

D302 VHD1N4148H/-1 AA Silicon,1N4148H

D305 VHD1N4148H/-1 AA Silicon,1N4148H

D705 VHDKDS160//-1 AB Silicon,KDS160

D706 VHDKDS160//-1 AB Silicon,KDS160

D707 VHDKDS160//-1 AB Silicon,KDS160

D708 VHDKDS160//-1 AB Silicon,KDS160

D709 VHDKDS160//-1 AB Silicon,KDS160

D711 VHDKDS160//-1 AB Silicon,KDS160

D712 VHDKDS160//-1 AB Silicon,KDS160

D713 VHD1N4148H/-1 AA Silicon,1N4148H

D714 VHD1N4148H/-1 AA Silicon,1N4148H

D801 VHDTS10B056-1 Silicon,TS10B056

D802 VHDTS4B056M-1 Silicon,TS4B056M

D803 VHDRL204F//-1 AC Silicon,RL204F

D804 VHDRL204F//-1 AC Silicon,RL204F

D805 VHDGD1N4004-1 AB Silicon,GD1N4004

D806 VHDGD1N4004-1 AB Silicon,GD1N4004

D842 VHDDS1N404S-1 AB Silicon,DS1N404S

D843 VHDDS1N404S-1 AB Silicon,DS1N404S

D844 VHDDS1N404S-1 AB Silicon,DS1N404S

D845 VHDDS1N404S-1 AB Silicon,DS1N404S

D846 VHD1N4148H/-1 AA Silicon,1N4148H

D851 VHD1N4148H/-1 AA Silicon,1N4148H

D852 VHD1N4148H/-1 AA Silicon,1N4148H

D853 VHDGD1N4004-1 AB Silicon,GD1N4004

Brand	Sharp
Model	XL-MP130
Category	Stereo System
Language	English

Sharp XL-MP130 Service Manual
