Sharp XL-MP130 Service Manual

XL-MP130
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
D855 VHD1N4148H/-1 AA Silicon,1N4148H
D856 VHD1N4148H/-1 AA Silicon,1N4148H
D857 VHD1N4148H/-1 AA Silicon,1N4148H
D858 VHD1N4148H/-1 AA Silicon,1N4148H
D859 VHD1N4148H/-1 AA Silicon,1N4148H
D860 VHD1N4148H/-1 AA Silicon,1N4148H
D905 VHD1N4148H/-1 AA Silicon,1N4148H
D906 VHD1N4148H/-1 AA Silicon,1N4148H
D907 VHD1N4148H/-1 AA Silicon,1N4148H
D909 VHDDS1N404S-1 AB Silicon,DS1N404S
D910 VHDDS1N404S-1 AB Silicon,DS1N404S
D911 VHD1N4148H/-1 AA Silicon,1N4148H
D912 VHD1N4148H/-1 AA Silicon,1N4148H
LED701 VHPSLR343VC3F AC LED,Red,SLR343VC3F
VD301 VHCSVC347S/-1 AG Variable Capacitance,SVC347S
VD302 VHCSVC230C/-1 AD Variable Capacitance,SVC230C
VD303 VHCSVC230C/-1 AD Variable Capacitance,SVC230C
ZD351 VHEDZ5R1BSB-1 AC Zener,5.1V,DZ5.1BSB
ZD801 VHEDZ6R2BSA-1 AB Zener,6.2V,DZ6.2BSA
ZD802 VHEDZ6R8BSA-1 AC Zener,6.8V,DZ6.8BSA
ZD803 VHEDZ300BSB-1 AB Zener,30V,DZ300BSB
ZD852 VHEDZ8R2BSB-1 AB Zener,8.2V,DZ8.2BSB
ZD853 VHEDZ150BSB-1 AB Zener,15V,DZ15BSB
ZD854 VHEDZ120BSB-1 AB Zener,12V,DZ12BSB
ZD855 VHEDZ6R2BSA-1 AB Zener,6.2V,DZ6.2BSA
ZD902 VHEDZ120BSB-1 AB Zener,12V,DZ12BSB
ZD903 VHEDZ120BSB-1 AB Zener,12V,DZ12BSB
[4] FILTERS
BF301 RFILR0008AWZZ AE Band Pass Filter
CF303 RFILF0124AFZZ AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ AK FM IF
CF352 RFILA0009AWZZ AE AM IF
[5] TRANSFORMERS
!
PT801 RTRNPA014AWZZ Power (Main)
!
PT841 RTRNP0483AWZZ AL Power (Sub)
T301 RCILBA001AWZZ AC OSC,FM
T302 RCILI0017AWZZ AB FM IF
T303 RCILA0052AWZZ AE AM Antenna
T306 RCILB0067AWZZ AD AM OSC
T351 RCILI0019AWZZ AD AM IF
[6] COILS
FB1 RBLN-0061TAZZ AB Ferrite Beads, BLM18AG121SN1D
FB2 RBLN-0061TAZZ AB Ferrite Beads, BLM18AG121SN1D
L103 VP-MK331K0000 AB 330 µ H,Choke
L312 RCILR0056AWZZ AB FM RF
L351 VP-DH101K0000 AB 100 µ H,Choke
L352 VP-DH101K0000 AB 100 µ H,Choke
L701 VP-DH101K0000 AB 100 µ H,Choke
L901 RCILZ0024AWZZ AC 3 µ H,Choke
L902 RCILZ0024AWZZ AC 3 µ H,Choke
L903 VP-DH2R2K0000 AB 2.2 µ H,Peaking
[7] VIBRATORS
X351 92LCRSTL1425A AF Crystal,456 kHz
X352 RCRSP0019AWZZ AF Crystal,4.5 MHz
XL1 RCRM-0047AWZZ AE Ceramic,16.9344 MHz
XL700 RCRSP0029AWZZ AF Crystal,8.388608 MHz
[8] CAPACITORS
C1 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C2A VCKYTV1HB102K AA 0.001 µ F,50V
C3 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C4 VCKYPA1HB103K AA 0.01 µ F,50V
C5 VCEAZA1EW476M AB 47 µ F,25V,Electrolytic
C6 RC-EZ0004AWZZ AD 3.3 µ F,16V,Electrolytic
C7 VCKYPA1HB102K AA 0.001 µ F,50V
C8 VCEAZA1AW476M AB 47 µ F,10V,Electrolytic
C9 VCKYCY1HB103K AA 0.01 µ F,50V
C10 VCEAZA0JW108M AC 1000 µ F,6.3V,Electrolytic
C11 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C12 VCKYCY1HB472K AA 0.0047 µ F,50V
C13 VCKYCY1HB103K AA 0.01 µ F,50V
C14 VCKYCY1EF473Z AB 0.047 µ F,25V
C15 VCKYCY1CB563K AB 0.056 µ F,16V
C16 VCKYCY1HB103K AA 0.01 µ F,50V
C17 VCKYCY1CB563K AB 0.056 µ F,16V
C18 VCKYCY1HB103K AA 0.01 µ F,50V
C19 VCKYCY1CB104K AB 0.1 µ F,16V
C20 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C21 VCKYCY1CB104K AB 0.1 µ F,16V
C22 VCEAZA1AW477M AC 470 µ F,10V,Electrolytic
[3] DIODES
