Sharp XL-MP130 Service Manual

XL-MP130
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
R858 VRD-ST2CD221J AA 220 ohms,1/6W
R859 VRD-ST2CD223J AA 22 kohms,1/6W
R860 VRD-ST2EE221J AA 220 ohms,1/4W
R863 VRD-RT2HD3R3J AA 3.3 ohms,1/2W
R890 RR-HZ0001AWZZ AE 4.7 Mohms,1/2W
R901 VRS-CY1JB563J AA 56 kohms,1/16W
R902 VRS-CY1JB563J AA 56 kohms,1/16W
R903 VRS-CY1JB102J AA 1 kohm,1/16W
R904 VRS-CY1JB102J AA 1 kohm,1/16W
R905 VRD-ST2CD561J AA 560 ohms,1/6W
R906 VRD-ST2CD561J AA 560 ohms,1/6W
R907 VRS-CY1JB563J AA 56 kohms,1/16W
R908 VRS-CY1JB102J AA 1 kohm,1/16W
R909 VRS-CY1JB333J AA 33 kohms,1/16W
R910 VRS-CY1JB102J AA 1 kohm,1/16W
R911 VRS-CY1JB563J AA 56 kohms,1/16W
!
R912 VRG-ST2EC101J AB 100 ohm,1/4W,Fusible
R913 VRN-VV3LAR22J AC 0.22 ohms,3W
R916 VRN-VV3LAR22J AC 0.22 ohms,3W
R917 VRN-VV3LAR10J AD 0.1 ohm,3W
R918 VRS-CY1JB152J AA 1.5 kohms,1/16W
R919 VRS-CY1JB472J AA 4.7 kohms,1/16W
R920 VRS-CY1JB472J AA 4.7 kohms,1/16W
R921 VRS-CY1JB152J AA 1.5 kohms,1/16W
R922 VRN-VV3LAR10J AD 0.1 ohm,3W
R925 VRD-RT2HD152J AA 1.5 kohms,1/2W
R926 VRD-RT2HD152J AA 1.5 kohms,1/2W
R927 VRD-ST2EE393J AA 39 kohms,1/4W
R928 VRD-ST2EE393J AA 39 kohms,1/4W
R929 VRD-ST2EE473J AA 47 kohms,1/4W
R930 VRD-ST2EE473J AA 47 kohms,1/4W
R934 VRD-ST2CD563J AA 56 kohms,1/6W
R935 VRD-ST2CD563J AA 56 kohms,1/6W
R937 VRS-CY1JB563J AA 56 kohms,1/16W
R938 VRD-RT2HD100J AA 10 ohm,1/2W
R939 VRD-RT2HD100J AA 10 ohm,1/2W
R940 VRD-RT2HD100J AA 10 ohm,1/2W
R941 VRD-RT2HD100J AA 10 ohm,1/2W
R942 VRS-VV3DA391J AC 390 ohms,2W
R943 VRS-VV3DA391J AC 390 ohms,2W
R944 VRD-ST2CD152J AA 1.5 kohms,1/6W
R945 VRD-ST2CD152J AA 1.5 kohms,1/6W
R946 VRS-CY1JB473J AA 47 kohms,1/16W
R947 VRD-ST2CD153J AA 15 kohms,1/6W
R949 VRD-ST2CD102J AA 1 kohm,1/6W
R950 VRS-CY1JB683J AA 68 kohms,1/16W
!
R958 VRG-ST2EC101J AB 100 ohm,1/4W,Fusible
R965 VRD-RT2HD822J AA 8.2 kohms,1/2W
R966 VRD-RT2HD822J AA 8.2 kohms,1/2W
R968 VRD-RT2HD391J AA 390 ohms,1/2W
RD01 VRS-CY1JB681J AA 680 ohms,1/16W
RD02 VRS-CY1JB821J AA 820 ohms,1/16W
RD03 VRD-ST2CD102J AA 1 kohm,1/6W
RD04 VRS-CY1JB152J AA 1.5 kohms,1/16W
RD11 VRS-CY1JB681J AA 680 ohms,1/16W
RD12 VRS-CY1JB821J AA 820 ohms,1/16W
RD13 VRS-CY1JB102J AA 1 kohm,1/16W
RD14 VRS-CY1JB152J AA 1.5 kohms,1/16W
RD15 VRD-ST2CD222J AA 2.2 kohms,1/6W
RD16 VRD-ST2CD272J AA 2.7 kohms,1/6W
RD17 VRS-CY1JB392J AA 3.9 kohms,1/16W
RD18 VRS-CY1JB681J AA 680 ohms,1/16W
RD19 VRS-CY1JB821J AA 820 ohms,1/16W
RD20 VRD-ST2CD102J AA 1 kohm,1/6W
RD21 VRS-CY1JB152J AA 1.5 kohms,1/16W
RD22 VRS-CY1JB222J AA 2.2 kohms,1/16W
RD23 VRS-CY1JB272J AA 2.7 kohms,1/16W
RD24 VRS-CY1JB392J AA 3.9 kohms,1/16W
RD25 VRS-CY1JB562J AA 5.6 kohms,1/16W
RD26 VRS-CY1JB103J AA 10 kohm,1/16W
[10] OTHER CIRCUITRY PARTS
BI601 QCNWNA317AWPZ AF Connector Ass'y,8/7Pin,with CNS3
BI703 QCNWN2747AWPZ AB Flat Wire,2Pin(A,B)
BI801 QCNWNA358AWPZ Connector Ass'y,11/10Pin,with CNS801
BI802 QCNWNA056AWPZ AF Connector Ass'y,7/6Pin,with CNS802
BI902 QCNWN2756AWPZ AF Connector Ass'y,5/4Pin,with CNS902
CNB1 QCNCWZO11AWZZ AC Socket,11Pin
CNP1 QCNCWZY16AWZZ AD Socket,16Pin
CNP2 92LCONE6P53253 AC Plug,6Pin
CNP3 92LCONE7P53254 AB Plug,7Pin
CNP3A 92LCONE6P53254 AC Plug,6Pin
CNP4 QCNCWZX11AWZZ AC Socket,11Pin
CNP5 92LCONE4P53254 AC Plug,4Pin
CNP6 QCNCM704GAFZZ AC Plug,7Pin
[9] RESISTORS
