Sharp XL-MP130 Service Manual

XL-MP130
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
CNP7 QCNCWZY14AWZZ AD Socket,14Pin
CNP101 QCNCM705GAFZZ AB Plug,7Pin
CNP301 92LCONE2P5268 AB Plug,2Pin
CNP303 QCNCM010PAWZZ AD Plug,14Pin
CNP701
A
QCNCWYP25AWZZ AE Socket,25Pin
CNP701
B
QCNCWYP25AWZZ AE Socket,25Pin
CNP702 QCNCWZY07AWZZ AC Socket,7Pin
CNP704 QCNCWZX14AWZZ AD Socket,14Pin
CNP706
A
QCNCWYP07AWZZ AC Socket,7Pin
CNP706
B
QCNCWYP07AWZZ AC Socket,7Pin
CNP708 QCNCW012EAWZZ AC Socket,5Pin
CNP801 QCNCM035KAWZZ Plug,10Pin
CNP802 92LCONE6P53253 AC Plug,6Pin
CNP902 92LCONE4P5267X AB Plug,4Pin
CNP971 92LCONE2P53253 AB Plug,2Pin
CNS101 -------- - Con. Ass'y,7Pin(Supplied at REF No.212)
CNS303 QCNCW010PAWZZ AE Socket,14Pin
CNS971 QCNWNA057AWPZ AC Connector Ass'y,2Pin
CNW3 QCNWN2699AWPZ AF Connector Ass'y,6/6Pin
!
F801 QFS-D402DAWNI AC Fuse,4A,125V
!
F802 QFS-D402DAWNI AC Fuse,4A,125V
!
F803 QFS-D202DAWNI AC Fuse,2A,125V
!
F804 QFS-D202DAWNI AC Fuse,2A,125V
!
F805 QFS-D402DAWNI AC Fuse,4A,125V
FFC1 QCNWN2700AWPZ AE Flat Cable,16Pin
FFC4 QCNWN2701AWPZ AD Flat Cable,11Pin
FFC7 QCNWN2741AWPZ AE Flat Cable,14Pin
FFC701 QCNWNA315AWPZ AE Flat Cable,25Pin
FFC702 QCNWN2740AWPZ AD Flat Cable,7Pin
FFC706 QCNWNA043AWPZ AD Flat Cable,7Pin
FL701 VVKNA12MM54-1 AU FL Display
FW901 QCNWNA277AWPZ AC Flat Wire,5Pin
JK690 QSOCJ0224AWZZ AC Jack,Video/AUX
JK701 QJAKM0004AWZZ AK Jack,Headphones
JK953 QSOCJA010AWZZ AD Sub Woofer Output
M1 92LMTR5529BASY AD Motor with Gear [Tray]
M1A 92LMTR5515CASY AS Motor with Chassis [Spindle]
M2 92LMTR5529BASY AD Motor with Gear [Main Cam]
M2A 92LMMTR1854A AP Motor with Gear [Sled]
M971 RMOTV0027AWZZ AM Motor,Air Cooling Fan(202-3)
!
RL841 RRLYD0018AWZZ AH Relay,AC
RL914 RRLYD0016AWZZ AH Relay,Speaker
RX1 VHPGP1S094HCZ AF Photo Interrupter
RX701 VHLK2013TH2E1 AG Remote Sensor,2013TH2E1
SO302 QTANC0206AWZZ AD Terminal,FM Antenna
SO901 QTANA0426AWZZ AE Terminal,Speaker
SP1 RSP-ZA084AWZZ AZ Woofer
SP2 RSP-ZA084AWZZ AZ Woofer
SP3 RSP-ZA085AWZZ Tweeter
SP4 RSP-ZA085AWZZ Tweeter
SW1 QSW-P9003AWZZ AD Switch,Push Type [CLAMP]
SW1A QSW-F9001AW01 AD Switch,Leaf Type [PICKUP IN]
SW2 QSW-P9003AWZZ AD Switch,Push Type [TRAY SW1]
SW3 QSW-P9003AWZZ AD Switch,Push Type [TRAY SW2]
SW4 QSW-P9006AWZZ AF Switch,Push Type [DISC]
SW701 92LSWICHT1663T AC Switch,Key Type [POWER ON/STAND-BY]
SW702 92LSWICHT1663T AC Switch,Key Type [CLOCK/TIMER]
SW703 92LSWICHT1663T AC Switch,Key Type [REC/PAUSE]
SW704 92LSWICHT1663T AC Switch,Key Type [PRESET UP]
SW705 92LSWICHT1663T AC Switch,Key Type [PRESET DOWN]
SW711 92LSWICHT1663T AC Switch,Key Type [VIDEO/AUX]
SW712 92LSWICHT1663T AC Switch,Key Type [TUNER (BAND)]
SW713 92LSWICHT1663T AC Switch,Key Type [PLAY/REPEAT]
SW714 92LSWICHT1663T AC Switch,Key Type [TUNING/TIME DOWN]
SW715 92LSWICHT1663T AC Switch,Key Type [TUNING/TIME UP]
SW716 92LSWICHT1663T AC Switch,Key Type [STOP]
SW717 92LSWICHT1663T AC Switch,Key Type [CD]
SW718 92LSWICHT1663T AC Switch,Key Type [TAPE]
SW719 92LSWICHT1663T AC Switch,Key Type [MEMORY/SET]
SW720 92LSWICHT1663T AC Switch,Key Type [EQUALISER]
SW721 92LSWICHT1663T AC Switch,Key Type [X-BASS/DEMO]
SW722 92LSWICHT1663T AC Switch,Key Type [DIRECT PLAY]
SW723 92LSWICHT1663T AC Switch,Key Type [DISC 1]
SW724 92LSWICHT1663T AC Switch,Key Type [DISC 2]
SW725 92LSWICHT1663T AC Switch,Key Type [DISC 3]
SW726 92LSWICHT1663T AC Switch,Key Type [DISC 4]
SW727 92LSWICHT1663T AC Switch,Key Type [DISC 5]
SW728 92LSWICHT1663T AC Switch,Key Type [OPEN/CLOSE]
VR701 QSW-Z0013AWZZ AF Switch,Rotary Type [VOLUME]
WTM901 QCNCW019EAWZZ AB Socket,5Pin
[10] OTHER CIRCUITRY PARTS
