Sharp XL-MP130 Service Manual

XL-MP130
17
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[13] CABINET PARTS
201 CCABA6247AW01 Front Panel Ass'y
201- 1 -------- - Front Panel
201- 2 GCOVA1364AWSA AB Indicator,Timer
201- 3 GCOVAA084AWSA AK Panel,Cassette Cover
201- 4 GDORF0117AWSA AF Holder,Cassette
201- 5 HBDGB1001AWSA AD Badge,SHARP
201- 6 HDECQA141AWSA AH Panel,FL Display
201- 7 HDECQA142AWSA AC Window,Cassette
201- 8 HDECQA143AWSA AC Indicator,Volume Knob
201- 9 HDECQA146AWSA AB Cover,Sensor
201-10 HDECQA147AWSA AL Decoration Panel
201-11 JKNBZA093AWSA AD Button,Power ON/STAND-BY
201-12 JKNBZA095AWSA AD Button,X-Bass
201-13 JKNBZA096AWSA AE Button,Disc Select
201-14 JKNBZA102AWSA AF Button,Function,A
201-15 JKNBZA098AWSA AF Button,Function,B
201-16 JKNBZA101AWSA AD Button,Play,A
201-17 JKNBZA100AWSA AF Button,Play,B
201-18 MLIFP0008AWZZ AD Damper
201-19 MLOKC0015AWZZ AC Lock Lever,Cassette
201-20 MSPRD0180AWFJ AB Spring,Cassette Lock Lever
201-21 MSPRD0197AWFJ AC Spring,Cassette Holder
202 CFANB5609AW01 AQ Fan Motor Ass'y
202- 1 LANGK0434AWFW AF Bracket,Fan Motor
202- 2 NFANP0001AWZZ AD Rotary,Fan
202- 3 RMOTV0027AWZZ AM Motor,Air Cooling Fan(M971)
202- 4 92LCSPR1431C AA Spring,Ring
203 92LCSPR1431C AA Spring,Ring
!
204 92LFSHOLD1652T AB Holder,Fuse
205 GCAB-A028AWSA AS Top Cabinet
206 GCOVAA085AWSA AF Disc Tray Cover
207 GITARA254AWSA AM Rear Panel
208 GITASA100AWSA AM Side Panel,Left
209 GITASA101AWSA AM Side Panel,Right
211 JKNBKA010AWSA Knob,VOLUME
212 KMECBA005AWZZ AZ Tape Mechanism Ass'y
212- 1 -------- - Record/Playback/Erase Head
212- 2 -------- - Motor with Pulley
212- 3 -------- - Tape Mechanism PWB Ass'y
212- 4 92PF522-063 AZ Clutch Ass'y Block
212- 5 -------- - Belt,Main
212- 6 92PF514-133 AL Pinch Roller Block,Right
212- 8 -------- - Belt,FF/REW
213 LANGT0042AWFW AC Bracket,PWB Support
214 LBND-1011AWZZ AA Nylon Band
!
215 LBSHC0005AWZZ AD Bushing,AC Power Supply Cord
216 LCHSMA027AWFW AQ Chassis,Main
217 LCHSZA007AWSA AN Chassis,Changer Unit
218 LHLDZ9024AWZZ AD Holder,FL Display
219 LHLDZA047AWZZ AC Holder,LED
220 PCUSG0022AWZZ AB Cushion,Leg
221 PRDARA067AWFW Heat Sink,Main
223 PSHEPA036AWZZ Edge Light Sheet
224 PSLDMA008AWFW AD Shield Plate
!
225 QACCD0022AWZZ AM AC Power Supply Cord
226 QCNWN1860AWZZ AC Lead Wire with Lug
227 QLUGP0001AWZZ AC Lug (LG2~5)
228 TSPC-A389AWZZ Label,Specification
229 92LNBAND1318A AA Nylon Band,80mm
602 LX-EZ0010AWFD AA Screw,Special
603 LX-JZ0010AFFD AA Screw,M3x10mm
604 LX-JZ0036AWFD AB Screw,Special
605 LX-JZ0037AWFD AB Screw,M3x12mm
606 XBBSD20P04000 AA Screw,M2x4mm
607 XEBSD26P08000 AA Screw,M2.6x8mm
608 XEBSD30P10000 AA Screw,M3x10mm
609 XEBSD30P12000 AA Screw,M3x12mm
610 XESSD30P10000 AA Screw,M3x10mm
611 XHBSD30P06000 AA Screw,M3x6mm
612 XHBSD40P06000 AA Screw,M4x6mm
613 XJBSD30P08000 AA Screw,M3x8mm
614 XJBSF30P08000 AA Screw,M3x8mm
615 XJSSD30P10000 AA Screw,M3x10mm
