RECEIVING YOUR BACTRON (CONTINUED)
Workspace Chamber Orientation (All Units)
Figure 5: Workspace Chamber Layout
Pass Box Orientation
Figure 6: Pass Box Inner Door and Sliding Shelf
The pass box-style airlock is provided with an integral sliding shelf to facilitate material transfers.
Small items may be introduced into the chamber via the Arm Port Doors and Sleeve Assemblies
using proper sleeve technique.
Pass Box Inner
Door Gasket
