Shel lab BACTRON300 - Orientation Photos

9 | P a g e
Figure 1: BACTRON900
Figure 2: BACTRON600
RECEIVING YOUR BACTRON (CONTINUED)
ORIENTATION PHOTOS
Gas and
Vacuum Ports
Main Control
Panel
Manometer
Side Storage Incubator
Pass Box
Workspace Chamber
Workspace Chamber
Incubator
Catalyst Cartridge
Gas and
Vacuum Ports
Workspace Incubator Control Panel
Side Storage Incubator
Pass Box
Right Arm Port
LED Lamp
Main Control
Panel (Side
Storage
Incubator)
Catalyst Cartridge
Manometer
LED Lamp
Left Arm Port
Right Arm Port
Left Arm Port
