PARTS LIST / SCHEMATICS / DIAGRAMS
Shelti Eye
2
Manual 35
SHELTI EYE
2
UPPER DISPLAY / LIGHTHOOD ASSEMBLY PARTS LIST
ITEM NO. PART NO. DESCRIPTION
12 J72-0-00-00 Lighthood Assembly
13 201-1103-0 Allen Key Screws
14 GK3-0-00-00 Fluorescent Light Fixture Assembly w/cord
15 223-1013-0 Fluorescent Light Bulb, 12VDC
16 217-0828-0 Fluorescent Light Cord
17 AD1-0-00-00 Upper Display Board
18 205-0969-0 Marquee Panel
19 201-0056-0 8-32 x 5/8 Black Machine Screw - (Qty 5)
