Shelti Eye 2 SD - A - E2 - Troubleshooting Guide; General Symptoms

PARTS LIST / SCHEMATICS / DIAGRAMS
Shelti Eye
2
Manual 26
TROUBLESHOOTING GUIDE
GENERAL SYMPTOMS
(1 of 3 pages)
Press
PLAYER
CHANGE
button to
override.
See
Administration,
Features
programming.
GAME LOCKING UP, NO
RESPONSE FROM COIN GAME
SWITCHES, TARGET OR
GAME RESETTING AT
RANDOM.
Grounding problem.
Be sure game is plugged
into a 3-wire outlet that
has GOOD earth ground.
Make sure ground wire
from coin mechanism is
securely fastened to the
common ground point.
Check power supply
harness connections for a
clean and tight fit.
Check tightness of
mounting hardware
on ALL boards.
Make sure connections on
Controller Board are
clean & tight.
Swap Controller Board.
Unplug power
supply for 5
seconds & reapply
power.
GAME
LOCKING UP
AFTER FIRST
3 DARTS.
Power cord not
fully connected
to power supply.
Check that pilot
light on power
supply is ON.
Overhead power
cable
disconnected.
GAME BEEPING
CONTINUALLY.
Segment jammed
(as shown in upper display).
Push on segment to release.
Dart tip stuck in between
segments.
Lower DCR board & inspect
for debris or tips.
Matrix Switch may be faulty.
Disconnect to verify.
Stuck game or coin switch.
Inspect switch for jamming.
Disconnect switch harness to
isolate Controller Board.
GAME
APPEARS
DEAD
Game
unplugged.
Power cable
disconnected.
Check Sleep
Mode setting.
