Shelti Eye 2 SD - A - E2 - Page 27

PARTS LIST / SCHEMATICS / DIAGRAMS
Shelti Eye
2
Manual 27
GENERAL SYMPTOMS
(3 of 3 pages)
WILL NOT
RESUME GAME
LOST IN
PROGRESS AFTER
POWER FAILURE.
Power failure recovery
disengaged.
See Administration,
Features Programming.
GAME FEATURES
NOT WORKING.
Software related.
Check for current version.
301 &/OR CRICKET
GAME ENDING
BEFORE FINISH.
Rounds Limits enabled.
Check Round Limits in
Programming Mode.
GENERAL SYMPTOMS
(2 of 3 pages)
OVERHEAD LAMP
IS OUT.
Make sure power cord is
plugged into Upper Display
light fixture.
Measure the voltage at light
fixture cord.
Voltage should be 12VDC.
When voltage is correct,
replace florescent lamp and/or
fixture.
Check light power cord for
proper connections.
PLAYER CHANGE
LIGHT IS OUT.
Check harnesses
&
connections to
Player Change Board.
Check Controller Board
connection.
KEYPAD FAILURES.
Check corresponding keypad
switch for closure.
Refer to Test Routine,
Keypad Test.
Check that Keypad Board is
snug and that ribbon cable is
properly secured in connector.
Check Controller Board
connector.
Swap Keypad Board
and/or
Controller Board.
