Shelti Eye 2 SD - A - E2 - Page 41

PARTS LIST / SCHEMATICS / DIAGRAMS
Shelti Eye
2
Manual 41
SHELTI EYE
2
USER INTERFACE DETAIL
ITEM NO. PART NO. DESCRIPTION
51 GK4-0-00-00 Control Panel Assembly
52 GH9-0-00-00 Keypad Assembly
53 GK1-0-00-00 Player Change Sensor Board
54 AD4-0-00-00 LCD Assembly
55 E5F-0-00-00 Interconnect Harness, Player Change & LCD
56 E5G-0-00-00 Ground Harness, LCD
57 217-0829-0 Player Change Sensor Antenna
58 205-0973-0 Player Change Lens
59 205-0970-0 Overlay, Control Panel
60 202-1014-0 Black Oxide Bolts – (Qty 6)
61 203-1033-0 Thumb Nut
62 203-1032-0 1/2” Nut for Bolts
