Shenzhen MG630 cutting plotter - Keypad and Display

14 / 21
14 / 21
Side 1 Side 2
1、 Left cover
2、 Limit switch
3、 Pinch roller wheels
4、 Carriage belt
5、 Upper cover
6、 Carriage
7、 Blade holder
8、 Grit roller
9、 LCD display 10、LCD display
4.1.2 keypad and display:
11、USB port
12、Serial port
13、U disc port
14、Power supply port
15、Switch
1 :
Go back
2:Forward
3:GO LEFT
4: GO RIGHT
5: ONLINE
6: MENU
7 PAUSE
8 RESET
9: Original
10: LCD
