4.2 Basic operation
CAUTION
When switching on the power, make sure your hands and
other articles are out of reach of such running parts as
main shaft and slider to prevent injury.
4.2.1 Turn on machine
4.2.1.1 Check whether the power is in OFF position.
4.2.1.2 Plug the cable into the receptacle of the host power source, press the power on/off
on the left.
4.2.2 Installation of cutting media
This machine is suitable not only for single-sheet media, but also a roll of media.
4.2.2.1 Press down the handle of pinch roller behind the machine to raise the handle
Pinch roller
4.2.2.2 Insert the media into the space between the pinch roller and grit roller, and pull out
the media to appropriate length from the front of the host.
4.2.2.3 Adjust horizontal position of paperweight
wheel according to width of paper. a distance
