126
ST SERIES
❱❘
❱❘
LIST OF SPECIAL TOOLS AND EQUIPMENT
Clutch block R-037
Magnetic fl ywheel extractor R-075
Bearing HK 808 (water pump) 2080
Engine starter shaft seal 2074
Pump shaft cap R232
Desmodromic bearing R465
Filter cover 4179
Cylinder head screws 10Nm
Cylinder nuts 22Nm
Magnetic fl ywheel cover screws 0.7Nm
Stator screws 0.7Nm
Magnetic fl ywheel nut 100Nm
Clutch spring screws 0,7Nm
Clutch nut 40Nm (with Loctite 243 sealer)
Intake nozzle screws 0.7Nm
Engine closure screws (carter) 15Nm
Primary cog nut 60Nm
M-5 Screws 0.6Nm
M-6 Screws 12Nm
M-8 Screws 24Nm
M-10 Screws 40Nm
Rear wheel axle nut 100Nm
Front wheel axle 100Nm
Lower steering nut 20Nm
Upper steering nut 20Nm
Tilting axle 50Nm
SPECIAL TOOLS
ENGINE TIGHTENING TORQUES
