48
CONDITION CAUSE REMEDY
No charging Is the flywheel (alternator) rotating?
Is the alternator generating?
1. The magnet damaged.
2. Some object seized.
3. The bearing defective.
4. The flywheel damaged.
Replace the alternator assembly.
1. Broken the stater coil.
2. Disconnect the out put wirings.
3. Reduced the flywheel magnet field.
1. Replace the alternator assembly.
2. Replace the stater or repair the wirings.
3. Replace the flywheel.
1. Faultly the regulator.
2. Faultly the battery.
3. Slip the V-belt.
4. Disconnect or misconnect the wirings.
1. Replace the regulator.
2. Replace the battery.
3. Adjust the V-belt tension.
4. Repair the wirings.
Abnormal sound 1. Some object seized.
2. The bearing defective.
1. Remove the object.
2. Replace the bearing.
N
O
N
O
YES
YES
Trouble Shooting (2)
