Shibaura CM214 - Chapter 3 TRACTOR MAIN BODY

64
Unit Part Inspection Item
Standard
Dimensions
Standard
Asembling Vlue
Repair Vlue
Service
Limit
Remarks
Type (Nozzle) 093400-2840 (ND-DNOSD189)
NIPPON
DENSO
Injection pressure MPa {kgf/cm
2
}
11.76
{120}
11.27 – 12.25
{115 – 125}
Injection angle
4°
Nozzle and holder tightening torque
N·m {kgf·m}
78.4 – 83.3
{8 – 8.5}
Install
cylinder
head
Cooling method Forced circulation water cooling
Cooling water amount ℓ 5.5
Thermostat operating temperature
°C
82 80 – 84
Thermostat full open temperature
°C
95
Pump discharge rate ℓ/mm
(Engine speed; 3000 rpm, Water
temperature: Normal)
54.4
V belt (fan) looseness (load at center
9.8 N {1 kgf })
5
Start to open pressure of radiator cap
p
ressure valve kPa{kgf/c
m
2
}
88.2 {0.9}
73.5 – 102.9
{0.75
–
1.05}
Start to open pressure of radiator cap
negative pressure valve
kPa{kgf/cm
2
}
4.9 {0.05}
3.9 – 4.9
{0.04 – 0.05}
Model 128000 – 0101
NIPPON
DENSO
No. of teeth of pinion gear 9
Pinion gear shifting method Magnetic shifting
Wear of commutator dia.
φ30 φ29
Pinion shaft axial play 0.1 – 0.5
Brush length 13.5 9.0
Brush spring pressure N {kgf} 1.7 1.2
Type GP9165
Kokusan
Denki
Type RS5137
Kokusan
Denki
Regulating voltage (V) 14.5 14 – 15
Electrical system
Starting motor
Alternator
Regulator
Cooling system
Cooling conditions
Injection nozzle
Fuel system
