* The W-AD Series comes equipped standard with smart auto doors, touchless sensors, ionizer, and adjustable windshield plate (semi-
micro models only). Refer to the following for other specifications.
Series Name W-AD Series
Model AP225W-AD AP135W-AD AP125WD-AD AP225WD-AD AP224W-AD AP324W-AD
Weighing Capacity 220g 135g 120g/52g 220g/102g 220g 320g
Minimum Display 0.01mg 0.01mg 0.1mg/0.01mg 0.1mg/0.01mg 0.1m g 0.1m g
Calibration Weight Built-in (*1)
Range of External
Weights for
Calibration Purposes
(Recommended
weight)
95~220.00090g
(200g)
45~135.00090g
(100g)
45~120.00090g
(100g)
95~220.00090g
(200g)
95~220.0090g
(200g)
95~320.0090g
(300g)
Repeatability
(when under
weighing capacity
load) (*2)
0.015mg
(up to 20g)/
0.03mg
(up to 100g)/
0.05mg
(up to 200g)
0.05mg 0.1mg/0.02mg 0.1mg/0.05mg 0.1m g 0.15 mg
Repeatability (when
under low load) (*2*3)
0,01mg (load weight 5g)
0.1mg
(load weight 10g)
0.1mg
(load weight 20g)
Minimum weighing
value (*2*3)
20mg 200mg
Linearity (*2) ±0.1m g ±0 .1m g
±0.2mg/
±0.05mg
±0.2mg/
±0.1m g
±0.2mg ±0.3mg
Display response
time for small
quantity weighing
(*4*5)
Approx. 2 sec.
Response Time (*5) Approx. 8 sec. Approx. 2 sec. / Approx. 8 sec. Approx. 2 sec.
Temperature/
Humidity Range
During Use
5~40°C, 20~85% (*6)
Sensitivity
Temperature
Coefficient
±2ppm/°C (10~30°C)
Pan Size Approximately 91DIA. mm
Main Unit
Dimensions
Approximately 212(W) × 411(D) × 345(H)mm
Approximately 212(W) × 367(D) ×
345(H)mm
Weight Approximately 9.7 kg Approximately 8.6 kg
Display Organic EL Display (Dot Matrix)
Rated Power Supply DC 12V , 1.5A
Degree of Soiling 2
Overvoltage Category
II
Altitude Maximum 2,000m
Installation
Environment
Limited to Indoor Use
Input Power Supply
(AC Adapter)
AC100-240V, 0.48A 50/60Hz (*7)
I/O Terminals RS232C(D-sub9P Plug) , USB host (Type A) , USB device (Type B), Ionizer
*1 Models with a minimum display of 0.01 mg come standard equipped with 2 built-in weights.
*2 The measurement conditions for the W-AD Series (semi-micro models only) are as follows.
· Adjustable windshield plate in the bottom position
· Pan area configuration using the shield plat
*3 USP41 compliant. Representative values from testing using weights equal to approximately 5% of the weighing capacity (or 5 g) at
the Shimadzu Corporation factory. The minimum display value will be affected by the environment in which the balance is installed,
so measurement needs to be carried out in the actual usage location.
*4 Time until 90% of the value of the sample quantity added in small quantity weighing (1 mg) is displayed.
*5 The response time is a representative value.
*6 No condensation.
*7 Depending on the attached AC adapter.
*8 The model names and specifications, etc., listed herein are subject to alteration without prior notice. Access the Shimadzu website
(https://www.shimadzu.com/an/balance/) for the latest information.
