Safety PrecautionsSafety Precautions
Caution Labels
Cautions labels are placed in necessary locations on the balance to ensure that it is used correctly.
In the event of these labels being mislaid or damaged, contact a Shimadzu sales office or service
agency to request new labels, and then make sure they are situated in the correct locations.
[AP224X example]
Residual Risk Information
Residual risk refers to the risks that could not be removed or reduced during the design and
manufacturing stages.
Check the [Residual Risk Maps] for each area with inherent risks and implement protective measures
while referring to the [List of Residual Risks].
Residual Risk Maps
The [Equipment Location] and [No.] shown below match up with the [List of Residual Risks].
Refer to the [List of Residual Risks] for further details.
O
K
FUNC
g
d
Location A: Balance Frame
! Caution
No.1
Location D: Internal windbreak plate (Option)
! Caution
No.3, 10
Location B: Ionizer (Option)
! Caution
No.6
Location C: Pan, Pan Supporter, Shield Plate, Shield case, Stage
! Caution
No.11
Location E: Power pack
! Caution
No.2
Location F: Multi stand, AP Holder
! Caution
No. 12
POWER
ION
ALARM
Location G : Glass draft shield
! Caution
No.5, 7, 13
Location J : touchless sensor
! Caution
No.8
Location I : Ionizer
! Caution
No.6
Location H : Adjustable Windbreak Plate
! Caution
No.4, 9, 13
Use the AC adapter supplied
with the specified power supply
To Next Page
