Shimadzu TOC-V CPH User Manual

TOCV-CP_IMshort_Control-ver-2_Rev07F Page 4 of 22
(Software version ≥ 2.00) effective date: September 2007
User
Name of current user is automatically entered, if entered it cannot
be edited
Date of Creation
Current date is automatically entered and cannot be edited
Comment
Enter additional system information (optional)
Instrument Setup Wizard-2 : Instrument Options
Parameter
Action / Description
Oxidation
Select “Combustion”
Options
Select the installed instrument components (TOC, ASI, SSM,
Sparge Kit and 8-port Sampler)
[The selected options determine which Instrument Setup Wizard
screens will subsequently be displayed.]
Instrument Setup Wizard-3 : Instrument Parameters
Parameter
Action / Description
Catalyst type
Select the catalyst type (Regular, High Sense or TC/TN)
Tubing Diameter
Regular
Suspended Particle
Select the diameter size of the sample injection tubing.
0.5 mm diameter
0.8 mm diameter
Cell length
Select the cell of the NDIR detection
(Long as default, short for SSM measurements)
TC Furnace
This item sets the TC furnace temperature
Buzzer
If this item is selected, a buzzer will sound with the press of each
instrument key
Auto regeneration of
IC solution
If this item is selected, IC reagent will automatically be generated in
special situations (Please refer to the User Manual)
Enable ready status
check
Select this option to enable the Ready Status Check function
[recommended, thus software always verifies Ready Status of
instrument prior to starting measurement]
TN Power
If this item is selected, the power to the optional TNM-1 is turned
on.
Instrument Setup Wizard-4 : ASI parameters
Parameter
Action / Description
Tray Type
Select ASI tray type (24 ml, 40 ml or 125 ml vial)
Needle Type
Select the needle type. (only active if Sparge Kit was selected)
No of Needle Washes
Select the number of times (0-10) the outside of the needle to be
washed with dilution water, after each sample analysis
No of Flow Line
Washes
Select the number of times (0-10) the flow lines to be washed with
dilution water from the needle to the injection tube, at the
completion of the sample sequence
Rinse
Select this option to rinse the sampling needle with dilution water
between each sample.
Rinse after acid
addition
Select this option to rinse the sampling needle after each acid
addition.
Stirrer on
Select this option to use the magnetic stirrer. (if installed)
