INSTALLATION/REMOVAL
Installing the brake hose
6. Check that the hose is secure, and then install the hose cutter.
Hose cutter
7. Press the hose cutter as shown in the figure to cut the brake hose.
8. Remove the hose cutter and check that the cut end is even.
90°90°
