INSTALLATION/REMOVAL
Installing the brake hose
9. Install the connector insert in the press block, and then set the press
block in tool TL-BH62.
Make sure that the tip of the connector insert is correctly positioned inside the opening
of the brake hose.
Press block
Connector insert
[1] [2]
NOTICE
• When connecting with an easy hose joint system, a specialized connector insert
(BL-M6100: SHIMANO CODE No.: Y8JA98020/color: silver, BL-M4100: SHIMANO
CODE No.: Y8H298040/color: gold) must be used. Use of any connector insert
other than the specified one may lead to oil leakage and other malfunctions.
