Quick guide
This section explains how to handle an assist bicycle that has had SHIMANO STEPS installed.
Depending on the assist bicycle used, the installed battery, cycle computer, and switch unit may differ from
what is listed here. Refer to the “ SHIMANO STEPS Special Battery and Parts User's Manual ”, “SHIMANO
STEPS Cycle Computer User's Manual” ( clamp band type / bracket installation type / switch unit integrated
type ) and “Switch Unit User's Manual ( with LED indicator function / without LED indicator function ).”
Charge the battery.
Example of external type battery
3
2
1
Lit up
Example of built-in type battery
3
2
1
Lit up
Lit up
Charging
Flashing
Charge error
According to the assist bicycle, the location of the charging port may be different from the one shown in
the figure.
1.
*
