SHIMANO STEPS battery
management systems and
compatibility
There are two generations of the SHIMANO STEPS battery management system: first generation and second
generation (Gen.2).
This manual only describes products compatible with Gen.2.
With some exceptions, first-generation and Gen.2 products of SHIMANO STEPS components are not compatible
with each other. For details, refer to the compatibility information on the SHIMANO product website (
https://productinfo.shimano.com/#/com ).
The Gen.2 battery and compatible battery mount are marked “Gen.2” as indicated in the figure.
Location of terminals
Battery (terminal) Battery mount (terminal)
SHIMANO STEPS battery management systems and compatibility
8
