22
2. Unlock the battery.
(1) Insert the key into the key cylinder in the battery mount.
(2) Turn the key.
(3) Push the key in.
The battery is unlocked. The plate spring holds the battery in place, preventing it from falling out.
(1)
(2)
(3)
(3)
Key cylinder
Key
3. Remove the battery.
(1) Remove the key, then close the keyhole cap.
(2) Remove the battery carefully.
NOTE
Do not install or remove the battery with the key left inserted on the battery mount or the keyhole cap left open.
The battery may be damaged by coming into contact with the handle of the key or the keyhole cap.
