Composition. 2.2.
Figure 1: main heat pump parts.
1 Fan protection net
2 Body
3 Display
4 Refrigerant charge valve (inside for BP-35WS-B)
5 Pressure manometer
6 Water outlet
7 Power cord
8 Water inlet
9 Plate heat exchanger
10 Fan
11 Compressor
12 Pressure sensor
13 Heat exchanger
14 Water sensor
15 Four way valve
6
16 Ambient sensor
7
17 Plate heat exchanger temperature sensor
8
18 Flow sensor
6
Not included in model BP-xxWS-B (xx=30, 35, 50).
7
Not included in model BP-xxWS-B (xx=30, 35, 50).
8
Not included in model BP-xxWS-B (xx=30, 35, 50).
