Shure ANTENNA SETUP - Antenna Combining: 2-4 Systems; Systems

See page 10,
“Active Antenna Combining”
for rear connections.
14
ANTENNA SETUP
Wireless Systems Guide for
Antenna combining: 5-8 systems
(1) 8-to-1 active combiner
Antenna combining: 2-4 systems
(1) 4-to-1 antenna combiner
12
345678
PA821
PSM Antenna Combiner
470-870 MHz.
50 OHMS
ACTIVE COMBINER
MAIN OUT
INPUT SIGNAL
A IN B IN A+B OUT
POWER
®
Shown: Shure PA821
with built-in 2-to-1
passive combiner
12
345678
PA821
PSM Antenna Combiner
470-870 MHz.
50 OHMS
ACTIVE COMBINER
MAIN OUT
INPUT SIGNAL
A IN B IN A+B OUT
POWER
®
