Shure ANTENNA SETUP - Remote Antenna: 100 Feet ( 30 M); Feet ( 20 M); Feet ( 15 M)

16
ANTENNA SETUP
Wireless Systems Guide for
Remote antenna – 75 feet,
Remote antenna – 50 feet,
Remote antenna – 100 feet,
Net Gain Calculation
Antenna 0 dB
Amplifier +10 dB
100’ RG213 Cable - 7 dB
Net Gain +3 dB ✓
Net Gain Calculation
Antenna 0 dB
Amplifier #1 + 3 dB
Amplifier #2 +10 dB
75’ RG8X Cable -10 dB
Net Gain +3 dB ✓
Net Gain Calculation
Antenna 0 dB
Amplifier +10 dB
50’ RG8X Cable - 6 dB
Net Gain +4 dB ✓
Amp # 1
Amp # 2
100 ft. (30 m) - RG213
25 ft. (7 m) - RG8X
50 ft. (15 m) - RG8X
50 ft. (15 m) - RG8X
˜
30 m
˜
20 m
˜
15 m
