Shure ANTENNA SETUP - Systems

15
ANTENNA SETUP
Wireless Systems Guide for
Antenna combining: 13-16 systems
(2) 8-to-1 active combiners
with 2-to-1 passive combiner
Antenna combining: 9-12 systems
• (1) 8-to-1 active combiner with
2-to-1 passive combiner
• (1) 4-to-1 active combiner
* For 9 systems, 4 input
combiner not needed.
