Shure GLXD4R Instructions

Note: Use only with the included power supply or a Shure-approved equiva-
lent.
System Overview
GLX-D Advanced Digital Wireless Systems combine Automatic Frequency
Management technology with a rack mountable metal receiver, rechargeable
lithium-ion batteries, world-renowned microphones, and unparalleled design
and construction. New GLX-D Advanced Frequency Managers (available
separately) connect multiple GLXD4R receiver systems for increased channel
count and improved RF reliability, consolidating RF to one pair of antennas.
New antenna accessories help improve reception by letting you mount anten-
nas closer to transmitters, with directional reception for improved performance.
Available in a variety of bodypack and handheld configurations, GLX-D Ad-
vanced Digital Wireless sets the standard for ease of operation and digital
audio clarity.
Features
• Exceptional digital audio clarity
• Operates in globally unlicensed 2.4 GHz spectrum
• Optional GLX-D Frequency Manager allows operation of up to 11 systems
• New antenna accessories for remote mounting and improved reception
• Half-rack size and metal chassis
• Rechargeable batteries deliver cost efficiency and up to 16 hours of
runtime
• Adjustable transmitter gain to optimize audio signal
• Automatically moves away from interference without audio interruption
• RF back-channel for remote control of transmitter functions
• Automatic transmitter power-off to conserve battery life when transmitter
is not in use
Furnished Accessories
95A32436Reverse SMA Bulkhead Adapters, lockwasher, nut (2)
95A21651USB Cable, Type A to Micro-B
UA802-RSMA0.6 m (2 ft.) Reverse SMA Cable (2)
PS43Power Supply
SB902 SB902Shure Lithium-Ion Rechargeable BatteryShure
Rechargeable Battery
Optional Accessories
UA846Z2-LCGLX-D Frequency Manager
PA805Z2-RSMAPassive Directional Antenna 2.4 GHz
UA221-RSMA
Reverse SMA Passive Antenna Splitter (900 MHz
ISM, DECT, 2.4 GHz)
UA505-RSMAWall Mount for PA805Z2-RSMA and UA8-2.4GHZ
UA8-2.4GHZ1/2 Wave Antenna, 45 deg. (2.4 GHz)
UA802-RSMA0.6 m (2 ft.) Reverse SMA Cable
UA806-RSMA1.8 m (6 ft.) Reverse SMA Cable
UA825-RSMA7.6 m (25 ft.) Reverse SMA Cable
UA850-RSMA15.2 m (50 ft.) Reverse SMA Cable
UA8100-RSMA30.4 m (100 ft.) Reverse SMA Cable
95A32436Reverse SMA Bulkhead Adapters
SBC10-902Stand Alone Single Battery Charger
SBC-CARCar Battery Charger
Quick Start for Single Receiver
To reduce set-up time, the transmitter and receiver automatically link to form an audio channel the first time they are powered on and never have to be linked
again.
Shure IncorporatedGLXD4R Half-Rack Wireless Receiver
2017/05/182/20

Shure GLXD4R Specifications

General

Impedance	50 Ω
Antenna type	Removable
Display type	LCD
Mounting type	Rack mount
Product color	Black
Scan features	Channel scan, Group scan
LED indicators	Yes
Housing material	Metal
Antennas quantity	2
Channels quantity	11 channels
High density mode	No
Antenna connector type	SMA
Operating frequency type	Ultra High Frequency (UHF)
Radio Frequency (RF) range	2404 - 2478 MHz
Operating temperature (T-T)	-18 - 57 °C
Microphone frequency response	20 - 20000 Hz
Total Harmonic Distortion (THD)	0.2 %
Input voltage	14 - 18 V
Power supply type	AC
Battery life (max)	16 h
Current consumption	550 mA
XLR out	1

Weight and Dimensions

Depth	163 mm
Width	197 mm
Height	42 mm
Weight	907 g
