Networked Charging Station Installation
The screws for attaching the mounting brackets to the charger are provided. Screws for securing the charger to another
surface are not included.
Important: The top of the screw must extend exactly 9/64 (0.149) inches (3.78 mm) above the surface (about 4 ½ threads).
Screws must be able to support 99.6 oz (2.8 kg) weight of charger.
Use the screws that best fit the thickness of the surface.
Use at least 3 screws to secure each mounting bracket to the charger.
Use at least 3 screws on each side to secure the mounting brackets to the rack or wall.
To install the charger:
Screw the mounting brackets to each side of the charging station.
