Shure Incorporated
9/93
3.
•
•
•
•
•
Listen to the sound check on the loudspeakers or headphone output.
Access Point Transceiver (MXCWAPT)
The access point transceiver is the hub of the audio signal flow and manages the RF stability of each microphone in the group.
The access point performs the following functions:
Receives and decrypts wireless audio signals from microphones in the group
Delivers and receives digital and analog audio signals via Dante and XLR
Hosts an embedded web server that provides access to the control software used to manage the system
Sends and receives control information (such as gain adjustment and link settings) between the components, control
software and 3rd party controllers
Transmits an encrypted audio signal to the microphone's headphone output for listening to translated audio or other
external sources.
