Shure MXCW - AES67 Compatibility and Configuration

Shure Incorporated
67/93
•
•
•
1.
2.
3.
4.
Porta TCP/UDP Protokol Deskripsi
2203 udp Kustom Diperlukan untuk packet bridge
4321,
14336-14600
udp Dante audio Dante
[4440, 4444,
4455]*
udp Dante Perutean audio Dante
5353 udp mDNS Digunakan oleh Dante
[8700, 8706,
8800]*
udp Dante Kontrol dan Pemantauan Dante
8751 udp Dante Dante Controller
16000-65536 udp Dante Digunakan oleh Dante
*Port ini harus terbuka pada PC atau sistem kontrol untuk mengakses perangkat melalui firewall.
†Protokolinimemerlukanmulticast.PastikankonfigurasimulticastuntukjaringanAndasudahbenar.
AES67
AES67 is a networked audio standard that enables communication between hardware components which use different IP
audio technologies. This Shure device supports AES67 for increased compatibility within networked systems for live sound,
integrated installations, and broadcast applications.
The following information is critical when transmitting or receiving AES67 signals:
Update Dante Controller software to the newest available version to ensure the AES67 configuration tab appears.
BeforeturningencryptiononoroffintheShuredevice’swebapplication,youmustdisableAES67inDanteController.
AES67 cannot operate when the transmit and receive devices both support Dante.
Shure Device Supports: Device 2 Supports: AES67 Compatibility
Dante and AES67 Dante and AES67 No. Must use Dante.
Dante and AES67
AES67 without Dante. Any other
audio networking protocol is
acceptable.
Yes
Separate Dante and AES67 flows can operate simultaneously. The total number of flows is determined by the maximum flow
limit of the device.
Sending Audio from a Shure Device
All AES67 configuration is managed in Dante Controller software. For more information, refer to the Dante Controller user
guide.
Open the Shure transmitting device in Dante Controller.
Enable AES67.
Reboot the Shure device.
Create AES67 flows according to the instructions in the Dante Controller user guide.
†
