Shure SCM262 - Ducking Threshold Modification

The aux ducking depth may be changed by removing resistor R213 and inserting a resistor into jumper X202.
Use the following tables to determine the proper resistor value for the desired ducking depth.
Ducking Depth
Resistor Value
6 dB
4,000 Ω
9 dB
5,000 Ω
15 dB
7,500 Ω
20 dB
10,000 Ω
24 dB
12,000 Ω
29 dB
15,000 Ω
Ducking Depth
Resistor Value

