Shure SCM262 User Manual

Ducking Depth
Resistor Value
36 dB
20,000 Ω
42 dB
25,000 Ω
47 dB
30,000 Ω
50 dB
33,000 Ω
55 dB
40,000 Ω
Ducking Threshold
This modification adjusts the threshold for activating the ducking circuit.
The ducking threshold can be raised or lowered by first removing resistor R333, and then placing a resistor (R) at
jumper X303. To lower the ducking threshold, use a resistor value (R) less than 2k ohms. To raise the ducking
threshold, use a resistor value (R) greater then 2k ohms.
Supplied Hardware
4 rubber feet. For stand-alone installation.
1 rackmount bracket, long. For half-rack (single unit) installations.
1 rackmount bracket, short. For half-rack (single) or dual-mount installations.
2 straddle brackets. For dual-mount or fixed installations.
12 bracket screws, 1/4-in. (6 mm). For securing the brackets to the chassis.
4 rackmount screws, 1 in. (2.5 cm). For mounting the unit in a rack.
4 plastic washers. For use with the supplied rackmount screws.
4 wood screws, 1/2 in. (1.25 cm). For fixed installations.

Publications

Shure SCM262 Specifications

General

Channels quantity	2 channels
Digital sound processing	- bit
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Microphone in	Yes
Line inputs (RCA)	3
Number of microphone inputs	2
Microphone input impedance	1400 Ω
Total Harmonic Distortion (THD)	0.25 %
Type	Stereo Microphone Mixer
DJ mixer	-
Product color	Black, Grey
Rack capacity	0.5U

Weight and Dimensions

Depth	162 mm
Width	218 mm
Height	43 mm
Weight	1100 g
