Siamp Monaco User Manual

32
Tools required:
• Set of keys from 8 to 19mm
• Metal saw
• Drill with a bit diameter 8mm
• Leveller
• Pencil & ruler
• Measuring tape
• Hammer
• Screwdriver
Advice:
• Keep this notice for any future
maintenance
 Read the instructions supplied with
the bowl, the cover, the tank and the
pressurised water supply system before
starting installation work.
Elbow bend xation clip
Elbow bend xation
Pipe xation clip
Pipe xation
Fixation screw and washer ( x4)
Bowl xing strip (x2), length 400mm
Flexible sleeve (x 2)
Bowl xing kit
Metal pegs (x6)
Adjustable legs (x2)
Punch screw
Wall brackets (x2)
Washer (x4)
Wall screw (x4)
Wall plugs (x4)
Collar bidet (x1)
a l
b m
c n
d o
e p
f
g
h
i
Evacuation kit elbow bend Ref. 92 4000-07
Evacuation kit straight Ref. 92 4010-07
ACCESSORIES (not supplied)
Evacuation kit
Elbow bend pipe
Straight pipe
Evacuation
pipe
Evacuation
pipe
j
k

Siamp Monaco Specifications

General

Water Type	Fresh Water
Adjustable Height	Yes
Material	Plastic
Adjustable Flush Volume	Yes
Flush Volume	6 liters
Compatibility	Compatible with most toilet cisterns
