4
TYPES OF INSTALLATION
USEFUL MEASUREMENTS
I
I - Minimum depth of the frame
= 140mm
II - Thickness of the cladding
Y – 400 – 80- x mm
Or, x = thickness of the cera-
mics at the bowl xation level
This calculation does not take
into account any constraints
due to the tank or pressu-
rised water supply.
III - Height : adjustable from
325 to 525mm
IV - Height of the bowl :
400mm (nished oor)
V - maximum thickness of the
nished oor = 185mm
III
V IV
➊
Fixed to a thin partition wall
➋
Built in to the rising column
II
y x
