Absolute Encoder
ATM60 SSI
ATM60 Encoders are state-of-the-art measu-
ring instruments.
• The Encoder must be installed by trained
personnel with knowledge of electrical
engineering and precision engineering.
• The Encoder must only be used for its
intended purpose.
Safety advice
• Observe the professional Safety and
Accident Prevention Regulations appli-
cable to your country.
• Switch off the voltage to all devices/
machines and systems affected by the
installation process.
• Never electrically connect or disconnect
the Encoder with the voltage switched
on, this may lead to damage to the unit.
• For the satisfactory operation of the
devices, ensure good earthing or an EM-
compatible screen connection (screen
connected at both ends).
• Avoid striking the shaft or collet.
Encoders with servo flange
This flange design offers two installation opti-
ons:
• via the 3 threaded holes on the flange side
or
• with servo clamps on the servo groove
Installation via threaded holes on the
flange side (F igure 1)
Lock the drive shaft on the application side .
Mount the coupling (1) on the Encoder;
ensure that it does not touch the Encoder
flange. Push the Encoder, with mounted cou-
pling (1), onto the drive shaft and mounting
spigot into the centring recess (2).
Fix the Encoder with 3 M4 screws (3).
Fix the coupling (1) to the drive shaft . The
coupling must not be subjected to any axial
stresses.
Make the electric connections with the volta-
ge switched off. Switch on the voltage and
check the operation of the Encoder.
Installation with servo clamps (Figure 2)
Lock the drive shaft on the application side.
Mount the coupling (1) on the Encoder;
ensure that it does not touch the Encoder
flange. Mount the servo clamps (2) with M4
screws (3).
Do not tighten screws, rotate the servo
clamps such that the Encoder flange can be
pushed into the centring recess.
Push the Encoder, with mounted coupling (1),
onto drive shaft and centring recess.
Place the servo clamp (2), into the groove,
and tighten lightly. Fix the coupling (1) to the
drive shaft. The coupling must not be subjec-
ted to any axial stresses.
Tighten all 3 screws of the servo clamps.
Make the electric connections with the volta-
ge switched off. Switch on the voltage and
check the operation of the Encoder.
Issue 03 / 10 • The right to make technical changes is reserved 8013417
