3.2 Product characteristics
3.2.1 Device view
50°
41.8 (1.65)
38.5
(1.52)
(27.4)
(1)
65.9 (2.59)
38.5 (1.52)
61 (2.4)
17.1 (0.67)
22.5
(0.89)
6.2
(0.24)
19.5
(0.77)
37.9 (1.94)
35.6
(1.4)
(25.4)
(1)
0.2
(0.1)
0.2
(0.1)
10 (0.39)
5.7
(0.22)
1
13.7 (0.54)
19.5 (0.77)
1
O
Ö
Ö
Ready
G Read
N Read
HW Err
UserDef1
O
Ö
7 6 5
4
2
3
Figure 4: CLV61x with front viewing window: Structure and device dimensions, unit of measure‐
ment: mm (inch), decimal separator: Period
1
Tapped blind hole M5, 5 mm deep (2 x), for mounting the device
2
Internal impact point: Rotation point of the variable direction laser beam
3
Central position of the deflected laser beam in the V-shaped aperture angle
4
Cable outlet, standard cable 0.9 m (+10 %) with male connector, D-Sub-HD, 15-pin
5
Viewing window, front orientation
6
RGB LED (1 x), status display with signal color allocation for events
7
Reference point of the reading distance (from housing edge to object)
PRODUCT DESCRIPTION 3
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
17
Subject to change without notice
