Feature CLV61x CAN CLV61x FIELDBUS CLV61x Dual Port (PROFINET)
Orientation of the viewing
window
•
CLV610, CLV612: front or side
•
CLV615, CLV618: side
Electrical Interfaces
•
Power
•
RS-232 (Host, AUX)
•
CAN
•
2 digital inputs
•
2 digital outputs
•
Power
•
Ethernet
(Host, AUX)
•
USB or MicroSD memory
card
1) 2) 3)
•
1 digital input
1)
Type of electrical connec‐
tions
1 cable with male connector, D-Sub-HD, 15-pin
•
2 female connectors, M12,
4-pin, D-coded in swivel con‐
nector
•
Cable with 1 male connector,
4- or 5-pin, A-coded
1)
•
1 female connector, 5-pin,
type USB Micro-B or MicroSD
memory card
1)
Supply voltage 10 V DC ... 30 V DC
•
10 V DC ... 30 V DC
•
18 V DC ... 30 V DC
4)
Power consumption
•
Typically 5 W
5)
•
Typically 15 W
4) 5)
Memory card – Optional
1) 2)
Heating – Optional
1)
Ambient operating tem‐
perature
0 °C ... +40 °C 0 °C ... +40 °C
–35 °C ... +40 °C
4)
Storage temperature –20 °C ... +70 °C –20 °C ... +70 °C
–35 °C ... +70 °C
4)
Dimensions for device
with front viewing window
61 mm x 66 mm x 38 mm 61 mm x 96 mm x 38 mm
Dimensions for device
with side viewing window
80 mm x 66 mm x 38 mm 80 mm x 96 mm x 38 mm
1)
Depending on type.
2)
USB interface or memory card shaft.
3)
USB interface is for temporary use as a service interface only.
4)
For device variants with integrated heating.
5)
For digital outputs without load.
PRODUCT DESCRIPTION 3
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
19
Subject to change without notice
