SICK CLV615 User Manual

(19)
(3.5)
10
11
4
38
10
48
16
22
10
19
(M5)
(Ø 7.5)
5
4
4
5
2
1
6
7
3
Figure 37: View of the quick release (dimensions in mm) and combination with mounting bracket
1
Width across flats, size 3
2
M5 threaded hole, max. screw-in depth 8 mm
3
Quick release (part number 2025526)
4
Quick release, part 1
5
Quick release, part 2
6
Width across flats, size 3
7
Mounting bracket (part number 2020410)
ACCESSORIES 13
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
73
Subject to change without notice

SICK CLV615 Specifications

General

Brand	SICK
Model	CLV615
Category	Barcode Reader
Language	English
