CLV620
Number of multiple readings 1 ... 99
1)
Reading interval: The time window generated internally by the reading cycle for code detection and evaluation.
NOTE
The bar codes being read must conform to at least quality level C in accordance with ISO/IEC 15416.
Interfaces
CLV620
Serial (RS-232,
RS-422/-485)
Function: Host, AUX (RS-232 only)
Data transmission rate: 2.4 kBd ... 115.2 kBd, AUX: 57.6 kBd (RS-232)
Ethernet Function: Host, AUX
Data transmission rate: 10/100 Mbit/s, half/full duplex
Protocol: TCP/IP, EtherNet/IP, PROFINET Single Port
CAN Function: SICK CAN sensor network (master/slave, multiplexer/server)
Data transmission rate: 20 kbit/s ... 1 Mbit/s
Protocol: CSN (SICK CAN sensor network), CANopen
PROFINET PROFINET Dual Port optional over external fieldbus module CDF600-2
EtherCAT
®
Optional via external fieldbus module CDF600
PROFIBUS DP Optional via external fieldbus module CDF600-2
DeviceNet Optional over external connection module CDM420 and CMF fieldbus module
Digital inputs 2 inputs (“Sensor 1”, “Sensor 2”), optional 2 additional inputs via CMC600 parameter cloning
module in the CDB650 or CDM420 connection module
Opto-decoupled, V
in
= max. 32 V, reverse polarity protected, can be wired via PNP output,
adjustable debounce time 0 ms ... 10000 ms
Digital outputs 2 outputs (“Result 1”, “Result 2”), optional 2 additional outputs via CMC600 parameter
cloning module in the CDB650 or CDM420 connection module
PNP, I
out
= max. 100 mA, short-circuit protected, adjustable pulse duration (static, 10 ms ...
10000 ms)
Reading pulse Pulse sources for start: Digital inputs “Sensor 1” and/or “Sensor 2”; Command (data inter‐
face), Auto pulse, CAN
Pulse sources for stop: Pulse sources for stop: Reading cycle source, digital inputs “Sensor
1”, “Sensor 2” Command, Timer, Condition (e.g., Good Read)
Optical indicators Not accessible
Acoustic indicator None
Control elements Configuration software
Service function Backup of parameterization data (parameter cloning) outside the device memory: External,
optional CMC600 parameter cloning module in CDB or CDM connection module
Configuration SOPAS ET configuration software, profile programming with bar codes (can be deactivated),
command language, GSD parameterization
Mechanics/Electronics
CLV620
Connection type 2 x round connections (1 x male connector, M12, 17-pin, A-coded, 1 x female connector,
M12, 4-pin, D-coded)
Supply voltage 10 V DC ... 30 V DC, LPS or NEC Class 2, reverse polarity protected
Power consumption
1)
Max. 4.5 W
Housing Stainless steel
Housing color Unpainted
7 TECHNICAL DATA
32
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/19ZB/2021-10-29 | SICK
Subject to change without notice
