66.1 Dibujo acotado
6.3
(0.25)
0.5
(0.02)
21
(0.83)
0.5
(0.02)
9.7
(0.38)
3
(0.12)
11.5
(0.45)
31.5 (1.24)
28.5 (1.12)
25.4 (1.00)
2.3
(0.09)
18.3
(0.72)
305 (12.01)
9.7
(0.38)
12
(0.47)
1
2
4
4
3
Figura 24: Dibujo acotado
1
Centro del eje óptico del emisor
2
Centro del eje óptico del receptor
3
Elementos de mando y visualización
4
Rosca de fijación M3
66.2 Diámetro del spot
Sensor
Ø 28
(1.10)
Ø 3.5
(0.14)
Ø 58
(2.28)
Ø 70
(2.76)
1
(3.28)
5
(16.40)
10
(32.81)
12
(39.37)
Distance in m (feet)
Diameter in mm (inch)
DATOS TÉCNICOS 66
8025389 / 24.06.2020 | SICK
Subject to change without notice
67

SICK GL6 Series Specifications

General

Product category	Accessories
Series	GL6
Protection class	IP67
Operating voltage	10-30 V DC
Ambient temperature	–25 °C ... +55 °C
Storage temperature	-40 °C to +70 °C
Housing material	Plastic
