11 Technical specifications
Laser class 1
Laser class 1
1)
Sensing range (with reflector P250F) 0.08 m ... 10 m
Sensing range max. (with reflector P250F) 0.08 m ... 12 m
Light spot diameter/distance 3.5 mm / 1,000 mm
Supply voltage U
B
DC 10 ... 30 V
2)
Output current I
ma
x.
30 mA
Switching frequency 1,000 Hz
3)
Max. response time 0.625 ms
4)
Enclosure rating IP67
Protection class II
5)
Circuit protection A, B, C
6)
Ambient operating temperature -20 ... +50 °C
1)
We recommend using compound triangular reflectors or reflective tape to ensure reliable operation. Suitable reflectors and foils can be
f
ound in the SICK accessories range. Use of reflectors with large-scale triple structures can negatively influence functionality.
2)
Limit values. U
B
connections reverse-polarity protected. Residual ripple max 5 V
PP
3)
With light / dark ratio 1:1
4)
Signal transit time with resistive load
5)
Reference voltage DC 50 V
6)
A = U
B
-c
onnections reverse polarity protected
B = inputs and output reverse-polarity protected
C = Interference suppression
TECHNICAL SPECIFICATIONS 11
8025389 / 24.06.2020 | SICK
Subject to change without notice
