SICK ICD890 User Manual

11 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/ICD89x
Please note: This documentation may contain further technical data.
11.1
Features
ICD890-x523xxxx ICD890-x434xxxx
Function Line-scan camera with integrated 1D / 2D code decoder, image output, and further optional 2D
vision functionality
Focus Dynamic focus control or fixed focus
Sensor CMOS line sensor
Type: High resolution
CMOS line sensor
Type: Standard resolution
Line frequency (scan‐
ning rate)
Max. 43 kHz Max. 50 kHz
Code resolution ≥ 0.1 mm
Working range 1,550 mm ... 3,900 mm
1)
1,550 mm ... 3,600 mm
1)
Field of view Covered conveyor width 1 800 mm at 170 dpi
resolution
Covered conveyor width 1 560 mm at 200 dpi
resolution
Conveyor width: 1,200 mm at 170 dpi resolution
Conveyor width: 1,035 mm at 200 dpi resolution
Operating mode Forward, Backward, Start/Stop
Lens Integrated
Focal length: 120 mm
Integrated
Focal length: 95 mm
2D Vision functional‐
ity
2)
•
Extended analysis of code quality
•
empty tote detection
•
hazardous material detection
•
object classification
•
2D dimensioning (image-based calculation of object dimensions)
1)
Relative to the device reference point, see "Field of view diagrams", page 39.
2)
For further 2D Vision functions, contact SICK Sales. To find your agency, see the final page of this document.
TECHNICAL DATA 11
8023775/18IM/2020-07-02 | SICK T E C H N I C A L I N F O R M A T I O N | Camera ICD890 Generation 4
35
Subject to change without notice
