SICK IME2S - Page 29

M12 x 1 M12 x 1
65
52,3
40,9
LED 2 x 180°
17
4
Figure 12: IME2S12-**B**C0 dimensional drawing
M12 x 1
M12 x 1
65
52,3
36,9
LED 2 x 180°
17
4
5
Figure 13: IME2S12-**N**C0 dimensional drawing
M12 x 1
63
52,3
40,9
300
LED 2 x 180°
17
4
Figure 14: IME2S12-**B**Q9 dimensional drawing
M12 x 1
63
52,3
36,9
300
LED 2 x 180°
17
5
4
Figure 15: IME2S12-**N**Q9 dimensional drawing
TECHNICAL DATA 11
8023341/14TD/2019-08-08 | SICK O P E R A T I N G I N S T R U C T I O N S | IME2S
29
